Arrizza s.r.l.

Machine features

Rear tool holder
Hydraulic widening controlled by multifunction joystick
Hydraulic inclination controlled by multifunction joystick
Double-acting cylinder parallelogram system with flow restrictor, equipped with quick coupling on toothed washer and feeler for blade or plow.
Hydraulic system powered by 2 quick couplings to the tractor (minimum oil flow rate 15 l/min and maximum 35 l/min required)
Predisposition for the application of driving tools such as compact wire cutter or shoot remover with drainage system of the hydraulic motor (to be connected directly to the free exhaust of the tractor)
Tap to exclude the parallelogram system or the driving tool and use the non-driving accessory
2-element electrodistributor to operate the widening and inclination from the Joystick
Cast iron filter with clogging indicator
Emergency recall of the tool controlled by joystick
RH and LH wheels with mechanical adjustment of the working height and lateral skidding resistance

ATTENTION:

to complete the configuration it is necessary to choose either the plow kit code 1434 or the inter-row blade code 1435

Contact request

Fille the form to get in touch.
The marked fields with * are required

Name, last name*

Email*

Message

I accept Terms and conditions

Configurator

Select model

Model	Code	Minimum power	Single widening	Machine width	Min width row	Weight

Expo single P 1	1722	40	30	143 / 173	193	140
Expo single P 2	1749	40	40	155 / 195	205	180
Expo single P 3	1660	40	50	170 / 220	220	210

Version

Front

Back

Agriculture Smart

Telemetric data interconnection and control system (ex. Industry 4.0) click here for info...

Select optionals

		Code	Description
		1450/S	Frame with reversible 3-point hitch. Bindings with adjustable center distance 68-90cm by including oversized wheel to be used when the machine is pushed. Applicable only when ordering.
		2112	Kit tank, double pumps, multiplier, filter, oil and maximum pressure regulator complete with single heat exchanger kit with thermostat and hydraulic kit for traction tool. For front and reversible versions specify into annotations box PTO type.
		0713	Single heat exchanger kit with thermostat.
		2108	RH parallelogram disk kit complete with bow and specific stump cleaner.
		1434	RH removing plow kit complete with bow and specific stump cleaner.
		1435	RH inter-row blade kit complete with arch and stump cleaner.
		1190	4m power cable (necessary for tractors without 3-pole female socket).
		1411	Power cable 4m extension.
		EJOYSCVPL004	3m extension cable for single channel and dual-channel joystick.
		2035	Adding cost for RH and LH 300 x 120 vulcanized rubber wheels with steel core installation (in substitution of standard wheels).
		1743	RH hydraulic with SMOOTH WHEEL adjustment with 2 quick tractor couplings. Only when ordering.
		1684	RH adjustable ground cover with shock absorber. (pay attention to the overall dimensions when flanging)
		APRTEESND034	RH kit cover fin extension for adjustable reinforced ground fender with rise strap.
		APRTEESND035	RH cover fin extension for adjustable reinforced ground fender.
		1437	Adapter to apply contemporarily front starcut blade set at 2/3 stars and rare fingerstar.
		1438	Adapter for fingerstar to be applied in substitution of plant lifting plough and inter-row blade.
		1665	Adapter to apply ridger bit disc or starcut blade set.
		ASTARDEXD031	Fingerstar diameter 54cm with predisposition for application on parallelogram cylinder (blue - hard).
		ASTARDEXD026	RH fingerstar diameter 70cm (red - hard).
		1264	Universal no traction adjustable ridger bit disc diameter 40cm.
		1312	RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk.
		1699	RH starcut blade 2 stars.
		ASTARSEXT025	RH starcut blade set with 3 stars.
		1440	Hydraulic shoot remover with oscillating adapter. Is not applicable with other driving and non-driving tools.
		1818/PDX	RH compact mower head complete with oscillating adapter with quick couplings for P models. Cannot be used simultaneously with other driving or non-driving tools.
