• The chiselling subsoiler for vineyards, thanks to special curve of its working utensils, allows for the vigorous, deep down breaking-up and lifting of the terrain. It improves the aeration of the terrain by eliminating any hard surfaces resulting from previous tillages (i.e. milling), as well as any compact terrain resulting from natural phenomenon and the passage of farming equipment
• With the application of fertiliser spreader become an effective fertilizers subsoiling for pellet, granular and microgranular fertilisers
• Open cochlea system with total emptying of tank
• Speed max 3 km/h
• Tool-carrier frame preset for the application utensils
• Pair of 600 mm curved chiselling teeth Michelle-type with 100x100 mm frame coupling
• Pair of hoses to bury the fertilizer to apply to the teeth Michel-type
• 380 liters (vers. 2 - 3 - ext.) or 280 liters (vers. 1 - 1S) stainless steel fertilizer spreader box, with helical hydraulic agitator (2 quick tractor couplings required), mechanical quantity adjustment and hydraulic closing with 1 quick coupling to the tractor. Possibility of increasing the cash register capacity by inserting a dedicated over-edge
• Pair of mini closed rollers to level the soil after the workmanship and manuring
• Pair of funnel conveyors (only for extensible version)

MECHANICAL WIDTH ADJUSTMENT ON THE FRAME

Aerator - subsoiling 1: cm 20 (total)

Aerator - subsoiling 2: cm 35 (total)

Aerator - subsoiling 3: cm 70 (total)

Aerator - subsoiling ext.: RH and LH hydraulic simultaneous widening 50+50 cm
