Machine features

Tool carrier with RH and LH lateral hydraulic simultaneously widening 2 cylinders double effect with LH side cut-off (is possible to choose independent hydraulic lateral widening with multifunction joystick: NO ADDITIONAL COST - ONLY WHEN ORDERING)
Available version with front or rear three-point hitch
Low PTO with cardan shaft
Hydraulic predisposition for traction utensils application RH and LH with FAUCET KIT
Double multiplier kit (Gr3) with 5 pumps, pipes, filters, tank and oil
Double heat exchanger with double control thermostat and self-cleaning system
18-channel electronic control unit
Electro-hydraulic distributor to control 6 double-effect cylinders
55 cm RH and LH inter-row blades (to be specified when ordering) with multifunction joystick for individually and simultaneously electro-hydraulic emergency recall of the blades
RH and LH buttons for feeler pin deactivation to work with the utensil in the tall grass, to avoid that the feeler pin goes back in when it is not necessary
Bulldozer-like tilling spurs
Kit RH and LH hydraulic toothed wheels “ZERO BULK” (NO IMPACT ON THE PLANTS BRANCHES) for depth adjustment and side stability control with multifunction joystick
Kit RH and LH hydraulic tool inclinations “ZERO BULK” (NO IMPACT ON THE PLANTS BRANCHES) with multifunction joystick

Contact request

Fille the form to get in touch.
The marked fields with * are required

Name, last name*

Email*

Message

I accept Terms and conditions

Configurator

Select model

Model	Code	Minimum power	Widening	Machine width	Min width row	Max width row	Weight

Double FULL UNDER 4	2070	50	70 + 70	210 / 350	260	520	111
Double FULL UNDER 4X	2071	50	100 + 100	248 / 448	298	618	222
Double FULL UNDER 4XL	2071	50	100 + 100	318 / 518	368	688	333

Select optionals

		Code	Description
		1190	4m power cable (necessary for tractors without 3-pole female socket).
		1411	Power cable 4m extension.
		1191	Extension 3m cable for multifunction joysticks 7+1.
		ECABLAGGU015	Extension 3m cable for multifunction joysticks 9+1.
		2035	Adding cost for RH and LH vulcanized rubber wheels with steel core installation (in substitution of standard wheels).
		1158/F	Push button for immediate RH rotary brush/mower head wire rotation stop. Applicable only when ordering.
		1159/F	Push button for immediate LH rotary brush/mower head wire rotation stop. Applicable only when ordering.
		0982	RH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade).
		0982/SX	LH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade).
		0695	RH blade with clod breaker, fin and feeler 65cm (additionally to standard blade).
		0695/SX	LH blade with clod breaker, fin and feeler 65cm (additionally to standard blade).
		0696	RH blade with clod breaker, fin and feeler 85cm (additionally to standard blade).
		0696/SX	LH blade with clod breaker, fin and feeler 85cm (additionally to standard blade).
		1160	RH non-stop feeler pin holder.
		1161	LH no-stop feeler pin holder.
		1085	RH oscillating feeler pin holder adjustable in height.
		1086	LH oscillating feeler pin holder adjustable in height.
		1767	RH reinforced adjustable fender ground cover in special steel with wear-resistant interchangeable sled. It can't use contemporary with no-traction ploughshare RH code 0702 and AARATROFR060. Note The codes 1767, 1405 e ADSCMEDXC012 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1768	LH reinforced adjustable fender ground cover in special steel with wear-resistant. Cannot be used at the same time as the LH lifter plough kit code 0725 and AARATROFR062. Note The codes ADSCMESXC001, 1768 e 1406 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		2052	RH and LH extension for adjustable reinforced ground fender
		2051	Kit covers fin extensions for RH and LH adjustable reinforced ground fender with rise strap.
		1409	RH adjustable and reinforced shock absorber.
		1410	LH adjustable and reinforced shock absorber.
		1405	RH ground fender with adjustable delimiter disc. Cannot be used at the same time as the RH lifter plough kit code 0702 and AARATROFR060. Note The codes 1767, 1405 e ADSCMEDXC012 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1406	LH ground fender with adjustable delimiter disc. Cannot be used at the same time as the LH lifter plough kit code 0725 and AARATROFR062. Note The codes ADSCMESXC001, 1768 e 1406 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		APRTEVDAM014	RH adjustable ground fender cover with shock absorber. Could be applied also with codes ADSCMEDXQ007 / ADSCMEDXC012 / AFRECSCDX001 / 0702 (only rear) / AARATROFR060 (only rear)
		APRTEVDAM031	LH adjustable ground fender cover with shock absorber. Could be applied also with codes ADSCMESXQ003 / ADSCMESXC001 / AFRECSCSX001 / 0725 (only rear) / AARATROFR062 (only rear)
		1050	RH stump cleaner for inter-row kit (remove the fixing plate when installing code 1247 RH vertical wires mower head).
		1051	LH stump cleaner for inter-row kit (remove the fixing plate when installing code 1248 LH vertical wires mower head).
		0483	RH sled for terrain with stones or superficial roots.
		1154	LH sled for terrain with stones or superficial roots.
		1187	RH 45cm inter-row plant lifting ploughshare.
		AVOMSQCDP009	RH 45cm inter-row plant lifting ploughshare with specify stump cleaner.
		1188	LH 45cm inter-row plant lifting ploughshare.
		AVOMSQCSP024	LH 45cm inter-row plant lifting ploughshare with specify stump cleaner.
		1268	RH 55cm inter-row plant lifting ploughshare.
		AVOMSCCDP021	RH 55cm inter-row plant lifting ploughshare with specify stump cleaner.
		1269	LH 55cm inter-row plant lifting ploughshare.
		AVOMSCCSP009	LH 55cm inter-row plant lifting ploughshare with specify stump cleaner.
		0702	RH plant lifting plough kit with front depth directional wheel.
		0725	LH plant lifting plough kit with front depth directional wheel.
		AARATROFR060	RH plant lifting plough kit with front depth directional wheel and specify stump cleaner.
		AARATROFR062	LH plant lifting plough kit with front depth directional wheel and specify stump cleaner.
		0488	RH no traction bulldozer-disk diameter 32cm.
		1157	LH no traction bulldozer-disk diameter 32cm.
		1267	Pair of adjustable no-traction universal rounded tiller discs diameter 36cm.
		1782	RH no traction adjustable rounded tiller disc diameter 36cm with quick tractor couplings hydraulic movement 15cm.
		1783	LH no traction adjustable rounded tiller disc diameter 36cm with quick tractor fast hydraulic couplings. Movement 15cm.
		1265	Pair of universal no traction adjustable ridger bit discs diameter 40cm.
		1784	RH no traction adjustable ridger bit disc diameter 40cm with quick tractor couplings and hydraulic. Movement 15cm.
		1785	LH no traction adjustable ridger bit disc diameter 40cm with quick tractor couplings and hydraulic. Movement 15cm.
		1312	RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk.
		1313	LH no traction adjustable ridger 2-discs diameter 40cm complete with cleaner on first disk.
		0657	Adapter for application of RH driving tools (15cm).
		1201	RH 3 kit disks non-traction non-driving toothed disks diameter 40cm.
		1286	LH 3 kit disks non-traction non-driving toothed disks diameter 40cm.
		1399	Adapter for application of LH driving tools (cm15).
		1279	RH 4 kit disks non-traction non-driving toothed disks diameter 40cm.
		1280	LH 4 kit disks non-traction non-driving toothed disks diameter 40cm.
		1281	LH 5 kit disks non-traction non-driving toothed disks diameter 40cm.
		1282	RH 5 kit disks non-traction non-driving toothed disks diameter 40cm.
		1419	RH starcut blade set with 2 stars. Note The codes 1419, ASTARDEXD024, 1767, 1405 e 1730 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1420	LH starcut blade set with 2 stars. Note The codes ASTARDEXS005, 1768, 1406, 1420 e 1731 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1730	RH starcut blade set with 3 stars. Note The codes 1419, ASTARDEXD024, 1767, 1405 e 1730 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1731	LH starcut blade set with 3 stars. Note The codes ASTARDEXS005, 1768, 1406, 1420 e 1731 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		ASTARDEXD034	RH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard).
		ASTARDEXS009	LH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard).
		ASTARDEXD032	RH fingerstar diameter 54cm (blue - hard).
		ASTARDEXS007	LH fingerstar diameter 54cm (blue - hard).
		ASTARDEXD024	RH fingerstar diameter 70cm (red - hard). Note The codes 1419, ASTARDEXD024, 1767, 1405 e 1730 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		ASTARDEXS005	LH fingerstar diameter 70cm (red - hard). Note The codes ASTARDEXS005, 1768, 1406, 1420 e 1731 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1203/SX	LH adapter to apply, on the fixed arm, a rotary tiller or hoe or mower head or set toothed disks.
		1247	RH vertical wires mower with adapter for Expo versions and wheel with mechanical adjustment for depth adjustment.
		1248	LH vertical mower head with adapter for Expo version and depth wheel with mechanical adjustment.
		1818	RH mower head complete with adapter, feeler and feeler holder.
		1819	LH mower head short wires, complete with adapter, feeler and feeler holder.
		1150	RH hydraulic rotary brush with gear motor and oscillating adapter.
		1151	LH hydraulic rotary brush with gear motor and oscillating adapter.
		0720	RH traction mower head with blades diameter 50cm.
		0720	LH traction mower head with blades diameter 50cm.
		ATRBLDX053	RH traction mower head with strings diameter 50cm.
		ATRBLDX053	RH traction mower head with strings diameter 50cm.
		0718	RH traction mini-shredder head 60cm.
		1040	LH traction mini-shredder head 60cm.
		2040	RH traction mini-shredder head 80cm complete with roller, feeler pin and floating adapter. The inter-row work area measures will increase obligatorily totally of 180cm on min. and max.
		2041	LH traction mini-shredder head 80cm complete with roller, feeler pin and floating adapter. The inter-row work area measures will increase obligatorily totally of 180cm on min. and max.
		ATRBLDX067	RH traction mower head with blades diameter 80cm.
		ATRBLSX013	LH traction mower head with blades diameter 80cm.
		1042	RH traction rotary plant lifter with 4 shedding fins diameter 40cm.
		1044	LH traction rotary plant lifter with 4 shedding fins diameter 40cm.
		1108	Nr.2 kit to change the rotative plant lifter into a 40cm diameter 3-hoes cutter.
		1043	RH traction rotary plant lifter with 4 shedding fins diameter 50cm.
		1045	LH traction rotary plant lifter with 4 shedding fins diameter 50cm.
		1099	Nr. 2 Kit to transform the rotary plant lifter in cutter 50cm diameter to 4 hoes.
		AFRCLEXDX021	RH circular cutter hydraulic kit for 55cm or 65cm inter-row blade.
		AFRCLEXSX007	LH circular cutter hydraulic kit for 55cm or 65cm inter-row blade.
		1403	RH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine for limited inter-row work.
		AFRECDCSX002	LH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine.
		AFRECSQDX011	RH traction 3-hoes hydraulic circular cutter diameter 40cm with brush.
		AFRECSQSX005	LH traction 3-hoes hydraulic circular cutter diameter 40cm with brush.
		AFRECQCDX025	RH traction 3-hoes hydraulic circular cutter diameter 40cm with engine.
		AFRECQCSX005	LH traction 3-hoes hydraulic circular cutter diameter 40cm.
		1295	Nr. 2 kit to change the cutter into a rotative plant lifter 40cm diameter to 4 fins.
		AFRECCCDX013	RH traction 4-hoes hydraulic circular cutter diameter 50cm.
		AFRECCCSX006	LH traction 4-hoes hydraulic circular cutter diameter 50cm.
		AADTMDX026	RH increased length adapter for traction tool application (30cm)
		AADTMSX008	LH increased length adapter for traction tool application (30cm)
		1294	Nr.2 Kit to change the circular cutter into a rotative plant lifter 50cm diameter to 4 fins.
		AFRECSCDX001	RH traction hydraulic circular cutter, 65cm diameter complete with 6-hoes .
		AFRECSCSX001	LH traction hydraulic circular cutter, diameter 65cm complete with 6-hoes.
		1288	LH traction 36cm diameter 2-lifting disc.
		1289	RH traction 2-lifting disc 36cm diameter.
		0717	RH traction disk set with 3 plant lifting disks diameter 36cm.
		1038	LH traction disk set with 3 plant lifting disks diameter 36cm.
		ADSCMEDXQ007	RH traction 36cm diameter 4-lifting disc for Expo.
		ADSCMESXQ003	LH traction 36cm diameter 4-lifting disc for Expo.
		ADSCMEDXC012	RH traction 36cm diameter 5-lifting disc for Expo Note The codes 1767, 1405 e ADSCMEDXC012 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		ADSCMESXC001	LH traction 36cm diameter 5-lifting disc for Expo Note The codes ADSCMESXC001, 1768 e 1406 can be inserted in the configuration but the machine can be equipped with only one option at a time..
		1384	RH stump cleaner on 2 / 3 / 4 traction disk set plant lifting disks diameter 36cm.
		1402	LH stump cleaner on traction disk set with 2/3 plant lifting disks diameter 36cm.
		1371	RH disk traction non-driving toothed disk diameter 40cm with working angle register.
		1372	LH disk traction non-driving toothed disk diameter 40cm with working angle register.
		1777	RH 2 kit disks traction non-driving toothed disks diameter 40cm with working angle register.
		1778	LH 2 kit disks traction non-driving toothed disks diameter 40cm with working angle register.
		1203	RH adapter to apply on the fixed arm a rotary tiller or hoe or mower head or set toothed disks.
		1775	RH 3 kit disks no-traction driving toothed disks diameter 40cm.
		1776	LH 3 kit disks traction non-driving toothed disks diameter 40cm.
		1773	RH 4 kit disks no-traction driving toothed disks diameter 40cm.
		1774	RH 4 kit disks traction non-driving toothed disks diameter 40cm.
		1757	RH 5 disks kit no-traction driving toothed disks diameter 40cm.
		1772	LH 5 kit disks traction non-driving toothed disks diameter 40cm.

Back to configuration New configuration

The marked fields with * are required

Name, last name* Email*

Province* City* Phone*

Table form

Model	Code	Minimum power	Widening	Machine width	Min width row	Max width row	Weight

Double FULL UNDER 4	2070	50	70 + 70	210 / 350	260	520	111
Double FULL UNDER 4X	2071	50	100 + 100	248 / 448	298	618	222
Double FULL UNDER 4XL	2071	50	100 + 100	318 / 518	368	688	333
