Machine features

  • Rear tool holder
  • SIMULTANEOUS enlargement with 2 hydraulic cylinders and LH side exclusion
  • Hydraulic tool inclination RH and LH
  • Pair of parallelogram systems, right and left, with double-acting cylinders equipped with quick coupling on toothed washer and feeler for blade or plow.
  • Hydraulic system powered by 2 quick couplings to the tractor
  • Single and simultaneous emergency recall of the tool controlled by Joystick
  • 3-element electrodistributor to operate the simultaneous widening and the two inclinations from the Joystick
  • 3-way tap to exclude the parallelogram system or the driving tool and use the NON-driving accessory
  • Predisposition for the application of driving tools such as compact mower head or shoot remover, with drainage system of the accessory engine oil (to be connected to the free exhaust of the tractor)
  • Cast iron filter
  • RH/LH wheel with mechanical adjustment of the working height and lateral skidding resistance


ATTENTION:

to complete the configuration is necessary to choose either RH and LH pair of plant lifting plough kit code 1454 or pair of RH and LH inter-row blades code 1455




Contact request

Fille the form to get in touch.
The marked fields with * are required

Configurator

Select model

Model Code Minimum power Widening Min width row Max width row Weight
Expo double P 1S 1467 60 15 + 15 185 225 385
Expo double P 1 1444 60 30 + 30 205 275 400
Expo double P 2 1445 60 40 + 40 225 315 420
Expo double P 3 1446 60 50 + 50 255 365 440
Expo double P 4 1552 60 60 + 60 260 390 480
Version
Agriculture Smart

Select optionals

Code Description
Chassis with reversible 3-point chassis. The attachments work with 68-90cm adjustable axis. 1450

Chassis with reversible 3-point chassis. The attachments work with 68-90cm adjustable axis.
RH and LH plant lifting plough kit with bow and specify trunk cleaner. 1454

RH and LH plant lifting plough kit with bow and specify trunk cleaner.
RH and LH inter-row blade kit complete with bow and specify trunk cleaner. 1455

RH and LH inter-row blade kit complete with bow and specify trunk cleaner.
Single heat exchanger kit with thermostat. 0713

Single heat exchanger kit with thermostat.
Electrohydraulic cast iron distributor with multifunction joystick to operate 5 double effect cylinders and 1 electrohydraulic emergency return (applicable only when ordering). 1748

Electrohydraulic cast iron distributor with multifunction joystick to operate 5 double effect cylinders and 1 electrohydraulic emergency return (applicable only when ordering).
4m power cable (necessary for tractors without 3-pole female socket). 1190

4m power cable (necessary for tractors without 3-pole female socket).
Power cable 4m extension. 1411

Power cable 4m extension.
Extension 3m cable for multifunction joysticks 7+1. 1191

Extension 3m cable for multifunction joysticks 7+1.
3m extension cable for single channel and dual-channel joystick. EJOYSCVPL004

3m extension cable for single channel and dual-channel joystick.
Adding cost for RH and LH vulcanized rubber wheels with steel core installation (in substitution of standard wheels). 2035

Adding cost for RH and LH vulcanized rubber wheels with steel core installation (in substitution of standard wheels).
RH and LH adjustable ground fenders with shock absorbers.  1456

RH and LH adjustable ground fenders with shock absorbers.
RH and LH extension for adjustable reinforced ground fender 2052

RH and LH extension for adjustable reinforced ground fender
Kit covers fin extensions for RH and LH adjustable reinforced ground fender with rise strap. 2051

Kit covers fin extensions for RH and LH adjustable reinforced ground fender with rise strap.
RH and LH adapters to apply contemporarily starcut blade set at 2/3 stars previously and fingerstar subsequently. 1458

RH and LH adapters to apply contemporarily starcut blade set at 2/3 stars previously and fingerstar subsequently.
RH and LH adapters for fingerstars. 1459

RH and LH adapters for fingerstars.
RH and LH adapters for application adjustable ridger bit discs or starcut blade. 1666

RH and LH adapters for application adjustable ridger bit discs or starcut blade.
RH and LH pair of fingerstar diameter 54cm (blue - hard). 2049

RH and LH pair of fingerstar diameter 54cm (blue - hard).
RH and LH fingerstars diameter 70cm (red - hard). 2031

RH and LH fingerstars diameter 70cm (red - hard).
RH hydraulic with SMOOTH WHEEL adjustment controlled by multifunction joystick. Only when ordering. 1241

RH hydraulic with SMOOTH WHEEL adjustment controlled by multifunction joystick. Only when ordering.
LH ydraulic with SMOOTH WHEEL adjustment controlled by multifunction joystick. Only when ordering. 1242

LH ydraulic with SMOOTH WHEEL adjustment controlled by multifunction joystick. Only when ordering.
Pair of universal no dribing no traction adjustable ridger bit discs.  1468

Pair of universal no dribing no traction adjustable ridger bit discs.
Pair of traction discs with 2 non-driving RH and LH orientable discs complete with cleaner on the first disc. 2003

Pair of traction discs with 2 non-driving RH and LH orientable discs complete with cleaner on the first disc.
Pair of 2-star RH and LH starcuts disks. 2004

Pair of 2-star RH and LH starcuts disks.
Pair of RH and LH starcut blade set with 2 stars. 2008

Pair of RH and LH starcut blade set with 2 stars.
RH and LH hydraulic rotary brush with oscillating adapters. It can't be used contemporarily with other traction and no traction accessories.ATTENTION a larger oil flow (MINIMUM 55 l / m) is required for the supply. 1461

RH and LH hydraulic rotary brush with oscillating adapters. It can't be used contemporarily with other traction and no traction accessories.

ATTENTION a larger oil flow (MINIMUM 55 l / m) is required for the supply.
RH and LH short wires mower head with oscillating adapters. It can't be used contemporarily with other traction and no traction accessories.ATTENTION a larger oil flow (MINIMUM 55 l/m) is required for the supply. 2011

RH and LH short wires mower head with oscillating adapters. It can't be used contemporarily with other traction and no traction accessories.

ATTENTION a larger oil flow (MINIMUM 55 l/m) is required for the supply.
Back to configuration New configuration

The marked fields with * are required

Table form

Model Code Minimum power Widening Min width row Max width row Weight
Expo double P 1S 1467 60 15 + 15 185 225 385
Expo double P 1 1444 60 30 + 30 205 275 400
Expo double P 2 1445 60 40 + 40 225 315 420
Expo double P 3 1446 60 50 + 50 255 365 440
Expo double P 4 1552 60 60 + 60 260 390 480
