SAN SALVO H

Machine features

  • Cultivator with 30x30 spiral spring and cage rollers
  • 65 cm RH side inter-row blade with quick tractor couplings and mechanic emergency blade return
  • 4,5 - 21 - 26 cm ploughshares (to specify during the order)
  • 60 or 100 cm RH lateral expansion with cage roller
  • Separately rear rollers mechanical adjustment
  • Sled for terrain with stones or superficial roots
  • Without wheels




Contact request

Fille the form to get in touch.
The marked fields with * are required

Configurator

Select model

Model Code Minimum power Springs Machine height Machine width Weight
San Salvo H 10 0753 60 10 53 220 640
San Salvo H 12 0754 60 12 53 265 680




Blade/s

Ploughshare

Industry 4.0

Select optionals

Code Description
Tank Kit for machine Version H including oil, filter, single pump, multiplier, pressure regulator with manometer and single heat exchanger kit with thermostat. (for front and reversible versions specify into annotations box PTO type) 1290

Tank Kit for machine Version H including oil, filter, single pump, multiplier, pressure regulator with manometer and single heat exchanger kit with thermostat. (for front and reversible versions specify into annotations box PTO type)

Hinge and cylinder for lateral extension hydraulic roll-over with 2 quick tractor couplings. Can only be installed on San Salvo and Basic 10-12 when ordering. 0671

Hinge and cylinder for lateral extension hydraulic roll-over with 2 quick tractor couplings. Can only be installed on San Salvo and Basic 10-12 when ordering.

Electrical emergency blade return for inter-row  1841

Electrical emergency blade return for inter-row

Hydraulic rollers adjustment with 4 quick tractor couplings. 0824

Hydraulic rollers adjustment with 4 quick tractor couplings.

Bulldozer-like tilling spur. 0694

Bulldozer-like tilling spur.

Nr. 10 adapters kit in boron steel complete of reversible soc and RH and LH laterals fins. 1335

Nr. 10 adapters kit in boron steel complete of reversible soc and RH and LH laterals fins.

Nr. 12 adapters kit in boron steel complete of reversible soc and RH and LH laterals fins. 1337

Nr. 12 adapters kit in boron steel complete of reversible soc and RH and LH laterals fins.

4m power cable (necessary for tractors without 3-pole female socket). 1190

4m power cable (necessary for tractors without 3-pole female socket).

Power cable 4m extension. 1411

Power cable 4m extension.

Pair of depth wheels 25x10cm with brackets. It cannot be installed on Futura H Ver.3, 5S, 5 and Vittoria/Basic Ver.3, 4, 5, 6. 0024

Pair of depth wheels 25x10cm with brackets. It cannot be installed on Futura H Ver.3, 5S, 5 and Vittoria/Basic Ver.3, 4, 5, 6.

RH hydraulic inter-row inclination with 2 quick tractor couplings. The width of the whole machine increases by 5cm. Only when ordering. 0698

RH hydraulic inter-row inclination with 2 quick tractor couplings. The width of the whole machine increases by 5cm. Only when ordering.

RH blade with clod breaker, fin and feeler 55cm (additionally at the standard blade). ALAMAINT029

RH blade with clod breaker, fin and feeler 55cm (additionally at the standard blade).

RH blade with clod breaker, fin and feeler 85cm (additionally to standard blade). 0696

RH blade with clod breaker, fin and feeler 85cm (additionally to standard blade).

RH non-stop feeler pin holder. 1160

RH non-stop feeler pin holder.

RH oscillating feeler pin holder adjustable in height. 1085

RH oscillating feeler pin holder adjustable in height.

RH stump cleaner for inter-row kit (remove the fixing plate when installing code 1247 RH vertical wires mower head). 1050

RH stump cleaner for inter-row kit (remove the fixing plate when installing code 1247 RH vertical wires mower head).

RH 45cm inter-row plant lifting ploughshare. 1187

RH 45cm inter-row plant lifting ploughshare.

RH 55cm inter-row plant lifting ploughshare. 1268

RH 55cm inter-row plant lifting ploughshare.

RH no traction bulldozer-disk diameter 32cm. 0488

RH no traction bulldozer-disk diameter 32cm.

Universal no traction adjustable rounded tiller disc diameter 36cm. 1266

Universal no traction adjustable rounded tiller disc diameter 36cm.

Universal no traction adjustable ridger bit disc diameter 40cm. 1264

Universal no traction adjustable ridger bit disc diameter 40cm.

RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk. 1312

RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk.

RH hydraulic system kit to install driving accessories. Only when ordering. 1341

RH hydraulic system kit to install driving accessories. Only when ordering.

RH circular cutter hydraulic kit for 55cm or 65cm inter-row blade. AFRCLEXDX021

RH circular cutter hydraulic kit for 55cm or 65cm inter-row blade.


The marked fields with * are required

Table form

Model Code Minimum power Springs Machine height Machine width Weight
San Salvo H 10 0753 60 10 53 220 640
San Salvo H 12 0754 60 12 53 265 680
